HONYPLAS® Die Mischung von Peek und Polyether kann bessere mechanische Eigenschaften und Flammenhemmung erzielen. Das Mischen von Peek und PTFE zum Herstellen von Verbundwerkstoffen hat einen hervorragenden Verschleißfestigkeit und kann zur Herstellung von Gleitlagern, dynamischen Dichtungsringen und anderen Teilen verwendet werden. Für Peek -Kohlefaser wird gefüllt und modifiziert, um verstärktes Peek -Verbundmaterial herzustellen, was die Härte, Steifigkeit und dimensionale Stabilität des Materials erheblich verbessern kann.
Nach dem Hinzufügen von Kohlefasern hat Peek mehr hervorragende hohe Temperatur- und Wärmewiderstand. Es kann für eine lange Zeit bei 300 ° C verwendet werden, und die momentane Verwendungstemperatur kann 360 ° C erreichen. Seine Starrheit, dimensionale Stabilität und lineare Expansionskoeffizient sind klein, was nahe an dem von Metallaluminium liegt. Kohlefaser weist eine gute chemische Stabilität auf, weist eine starke Korrosionsresistenz gegen Säuren, Alkalien und fast alle organischen Lösungsmittel auf und weist flammhemmende und strahlungsbeständige Eigenschaften auf. Peek Plus Carbonfaser hat eine hervorragende Verschleiß- und Verschleißfestigkeit, insbesondere bei 300 ° C aufrechtzuerhalten. Mit diesen hervorragenden umfassenden Eigenschaften werden Peek plus Kohlefaser-Kunststoff-Rohstoffe hauptsächlich in Automobil- und Luft- und Raumfahrt-Motorboxen, Scheinwerferreflektoren, Wärmeaustauschteilen, Ventilauskleidungen und Ölfeldteilen, Maschinen, Erdöl, Chemikalie, Kernkraft, Schiene und Schiene verwendet Transit, Elektronik und Medizin haben eine Vielzahl von Anwendungen.
Material
Material name
|
Compound %
|
Main Properties
|
Color
|
PTFE
|
-
|
Very low coefficient of frication and excellent chemical resistance,Food grade
|
White
|
Glass Filled PTFE
|
Up to 40%
|
Improved ware resistance , compression strenght,creep resistance,chemical resistance.Good performance in oxidising environment,good creep resistance
|
White cream
|
Carbon Filled PTFE
|
Up to 35%
|
Improvement electrical and termal conductivity,resistance to load,low coefficient of friction in dry,water,steam applications,chemical resistance.Superior ware resistance increase and low friction properties
|
Black
|
Graphit Filled PTFE
|
Up to 25%
|
Improve wear resistance,decrease friction and increase sliding prperties against soft metals-chemical inertness.Improve the temperature resistance in some way.
|
Black
|
Bronze Filled PTFE
|
Up to 60%
|
Improve compression strength,wear resistance,high thermal conductivity,resistance to abrasion.Reduced chemical resistance.
|
Dark brown
|
Molybdenum disulphide(MoS2)
|
Up to 5%
|
Increased PTFE properties of hardness and wear resistance .Increased sliding properties and decrease friction.
|
Blue azure
|
PEEK Filled PTFE
|
Up to 20%
|
Increased thermal resistance,sliding properties , surface hardness,Superior properties on dynamic applications.
|
Light Brown
|
PEEK
|
-
|
Excellent mechanical properties including strength.rigidity , impact resistance,low wear rate and low coefficient of friction , retained over a wide range of service temperature
|
Light Brown
|
PEEK compound
|
-
|
Improves technical and chemical properties like deformation under load,wear resistance,thermal expansion and electrical conductivity
|
-
|
PVDF
|
-
|
Resistance to UV radiation and offers high mechanical strength and abrasion resistance
|
Beige
|
PCTFE
|
-
|
Better mechanical properties than other fluoropolymers , low permeability
|
Translucent
|
PFA
|
-
|
Better mechanical properties than other fluoropolymers , low permeability
|
Natural
|
